説明
– Multimode Pump+Signal combiner
Configuration | Pump fiber | Signal fiber | Output fiber | Power per input | Singal insertion loss | Min. efficiency | Package |
---|---|---|---|---|---|---|---|
(2+1)x1 | 105/125µm, 0.22NA | x/125 SC or DC | x/125 DC | 50W | 0.35dB | 0,9 | P30,P31,P32 |
(2+1)x1 | 105/125µm, 0.22NA | x/125 SC or DC | y/125 DC | 50W | 0.7dB | 0,9 | P30,P31,P32 |
(2+1)x1 | 105/125µm, 0.22NA | x/125 SC or DC | y/250 DC | 50W | 0.7dB | 0,93 | P32 |
(2+1)x1 | 105/125µm, 0.22NA | x/250 SC or DC | x/250 DC | 50W | 0.5dB | 0,93 | P32 |
(2+1)x1 | 200/220µm, 0.22NA | x/250 SC or DC | x/250 DC | 50W | 0.5dB | 0,9 | P32 |
(2+1)x1 | 200/220µm, 0.22NA | x/400 DC | x/400 DC | 50W | 0.5dB | 0,9 | P32 |
(6+1)x1 | 105/125µm, 0.15NA | x/125 SC or DC | x/125 DC | 25W | 0.7dB | 0,9 | P32 |
(6+1)x1 | 105/125µm, 0.15NA | x/125 SC or DC | y/125 DC | 25W | 0.7dB | 0,93 | P32 |
(6+1)x1 | 105/125µm, 0.22NA | x/125 SC or DC | y/250 DC | 50W | 0.7dB | 0,93 | P32 |
(6+1)x1 | 200/220µm, 0.22NA | 20/400 DC | 20/400 DC | 100W | 0.7dB | 0,95 | P32, P33 |
(18+1)x1 | 105/125µm, 0.15NA | x/125 SC or DC | x/200 DC | 50W | 0.8dB | 0,95 | P32, P33 |
(18+1)x1 | 105/125µm, 0.22NA | x/125 SC or DC | x/400 DC | 50W | 0.8dB | 0,95 | P32, P33 |
Notes:
1. x, y= different core diameter ;
2. SC: Single Cladding, DC: Double Cladding
– Multimode Pump+Polarisation Maitaining Signal combiner
Configuration | Pump fiber | Signal fiber | Output fiber | Power per input | Singal insertion loss | Min. efficiency | Package |
---|---|---|---|---|---|---|---|
PM (2+1)x1 | 105/125µm, 0.22NA | x/125 SC or DC | x/125 DC | 50W | 0.35dB | 0,9 | P30,P31,P32 |
PM (2+1)x1 | 105/125µm, 0.22NA | x/125 SC or DC | y/125 DC | 50W | 0.7dB | 0,9 | P30,P31,P32 |
PM (2+1)x1 | 105/125µm, 0.22NA | x/125 SC or DC | y/250 DC | 50W | 0.7dB | 0,93 | P32 |
PM (2+1)x1 | 105/125µm, 0.22NA | x/250 SC or DC | x/250 DC | 50W | 0.5dB | 0,93 | P32 |
PM (2+1)x1 | 200/220µm, 0.22NA | x/250 SC or DC | x/250 DC | 50W | 0.5dB | 0,9 | P32 |
PM (2+1)x1 | 200/220µm, 0.22NA | x/400 DC | x/400 DC | 50W | 0.5dB | 0,9 | P32 |
PM (6+1)x1 | 105/125µm, 0.15NA | x/125 SC or DC | x/125 DC | 25W | 0.7dB | 0,9 | P32 |
PM (6+1)x1 | 105/125µm, 0.15NA | x/125 SC or DC | y/125 DC | 25W | 0.7dB | 0,93 | P32 |
PM (6+1)x1 | 105/125µm, 0.22NA | x/125 SC or DC | y/250 DC | 50W | 0.7dB | 0,93 | P32 |
PM (6+1)x1 | 200/220µm, 0.22NA | 20/400 DC | 20/400 DC | 100W | 0.7dB | 0,95 | P32, P33 |
PM(18+1)x1 | 105/125µm, 0.15NA | x/125 SC or DC | x/200 DC | 50W | 0.8dB | 0,95 | P32, P33 |
PM (18+1)x1 | 105/125µm, 0.22NA | x/125 SC or DC | x/400 DC | 50W | 0.8dB | 0,95 | P32, P33 |
Notes:
1. x, y= different core diameter ;
2. SC: Single Cladding, DC: Double Cladding
追加情報
型番 | Pump+Signal 光ファイバーコンバイナ |
---|---|
Configuration | (2+1)x1, (6+1)x1, (18+1)x1, PM (2+1)x1, PM (6+1)x1, PM (18+1)x1 |
メーカー | PhotonTec |
